DP(DisplayPort) Driver Board 3K 4K 5K IPS UHD LCD Panel

---The LCD features can be looked up via the following link:

http://www.panelook.com/
How to drive 3200*1800 or 3840*2160 LCD?
---4K 5K DP board:

http://cgi.ebay.com/ws/eBayISAPI.dll?ViewItem&item=191794197023
---15.6inch 3840*2160 eDP UHD LCD with Wide Viewing Angle :
......LP156UD1-SPB1
......LP156UD1-SPA2

http://cgi.ebay.com/ws/eBayISAPI.dll?ViewItem&item=401102708073
---23.8inch 3840*2160 eDP UHD LCD with Wide Viewing Angle :
......LM238WR2-SPB1
......LM270WR2-SPA1

http://cgi.ebay.com/ws/eBayISAPI.dll?ViewItem&item=401055091541
---As far as I know, the graphic card has to be the 4th generation haswell/maxwell structure.
---The DP signal will be DP1.2. The DP signal cable will be the standard DELL brand. The LCD will be blink if you use the normal DP cable. The normal DP cable cannot effectively prevent interference outside.
---The following graphic card can be used for my DP board:
......AMD Radeon HD77** Series: HD7750 HD7770 HD7800 HD7900 HD7990
......AMD Radeon R5 Series
......AMD Radeon R7 Series
......AMD Radeon R9 Series
......GTX760 765M
......GTX770M
......GTX780M
......GTX800M 820M 830M 840M 850M 860M 870M 880M
......GTX9**M

The DP board sets can be used for driving 3K 4K 5K eDP IPS LCD:
---resolution : 2048*1536 eDP IPS LCD:
......LP097QX2-SPAV
---The resolution of PC/notebook graphic card has to be equal or higher than 2048*1536. Or else, the LCD cannot show the normal image.
---As far as I know, the following graphic card can be used for my DP board:
......HD4600
......GTX760 or higher
......Geforce 750M
---resolution : 2048*1536 eDP IPS LCD:
......LP097QX1-SPA1
......LP097QX1-SPA2
......LTL097QL01-A01
......LTN097QL01-A02
---The resolution of PC/notebook graphic card has to be equal or higher than 2048*1536. Or else, the LCD cannot show the normal image.
---As far as I know, the following graphic card can be used for my DP board:
......HD4600
......GTX760 or higher
......Geforce 750M
---13.3inch 2560*1440 eDP LCD with Wide Viewing Angle :
......LQ133T1JW01
......LQ133T1JX03

http://cgi.ebay.com/ws/eBayISAPI.dll?ViewItem&item=401062440632
---13.3inch 2560*1440 eDP LCD with Wide Viewing Angle :
......LQ133T1JW02
......LQ133T1JW21

http://cgi.ebay.com/ws/eBayISAPI.dll?ViewItem&item=191779967422
---14.0inch 2560*1440 eDP LCD with Wide Viewing Angle :
......B140QAN01.0
......B140QAN01.1
......LP140QH1-SPA2
......LP140QH1-SPB1

http://cgi.ebay.com/ws/eBayISAPI.dll?ViewItem&item=191814575452
---15.5inch 2880*1620 eDP LCD with Wide Viewing Angle :
......VVX16T010D00
......VVX16T010J00
......VVX16T020G00
......VVX16T028J00
......VVX16T029D00

http://cgi.ebay.com/ws/eBayISAPI.dll?ViewItem&item=191812854267

---The power adapter for the board is DC+12V 3.0A.

---The board cannot be turned on if the DP signal cable isn't connected to the DP board.
---The brightness of the LCD can be adjusted via the power button alone on the keyboard.
---Please press te hpower button for 1-2 seconds. Don't loosen your finger. Then you can enter into brightness adjustment mode.
---The LCD brightness can be adjusted via press the power button.
---Please press the power button for 1-2 seconds. Don't loosen your finger. You can close the brightness adjustment mode.

The Related Items for the Controller Board:
---12V DC Adapter:
http://cgi.ebay.com/ws/eBayISAPI.dll?ViewItem&item=400737854240
---DP to DP Cable:
......2.0m / 2.18yd
---Mini DP to DP Cable:
......2.0m / 2.18yd


File Download:
Datasheet_LP097QX1-SPA1.pdf
Datasheet_LP097QX2-SPAV.pdf
Datasheet_LP129QE1-SPA1-2560x1700.pdf
Datasheet_LQ133T1JW02.pdf
Datasheet_LTN133YL01-L01.pdf
Datasheet_LP140QH1-SPA2_eDP2560x1440 40pin.pdf
Datasheet_VVX16T028J00.pdf
Datasheet_LTN156FL02-L01.pdf
Datasheet_B173ZAN01.0.pdf
Datasheet_LM270WR2-SPA1.pdf
